lMaterial - Aluminum Body
lFixed Orifice Disk- Brass
lSeal O-Ring- Rubber
lKnob- ABS Plastic
lEncased in an anodized aluminum housing
lEasy to read window
lCalibrated - Inlet pressure 50 PSIG
lInlet Port -1/8 FNPT
lSmallest and lightest in the industry
lGas specific color-coded labeling
lOutlet Port -9/16-18 UNF (CGA 1240)
lAvailable in Oxygen in 25, 15, 8 and 4 LPM
lAvailable in Medical Air in 25 and 15 LPM
|
Flow Range |
Oxygen |
0 - 25 LPM |
0, 1, 2, 3, 4, 6, 8, 10, 12, 15, 20, 25 |
|
0 - 15 LPM |
0.5, 1, 1.5, 2, 3, 4, 5, 6, 8, 10, 15 |
||
|
0 - 8 LPM |
0.5, 1, 1.5, 2, 2.5, 3, 4, 5, 6, 7, 8 |
||
|
0 - 4 LPM |
0, 0.03, 0.06, 0.12, 0.25, 0.5, 0.75, 1, 1.5, 2, 3, 4 |
||
|
Medical Air |
0 - 15 LPM |
0.5, 1, 1.5, 2, 3, 4, 5, 6, 8, 10, 15 |
|
|
0 - 25 LPM |
0.5, 1, 2, 4, 6, 8, 10, 12, 15, 20, 25
|
